Non Ferrous Alloys

Name: Non Ferrous Alloys
Brand: JAYANT IMPEX
Price: 5000.0 INR
Availability: InStock

5000.0 INR/Piece

Get a Price/Quote

Product Details:

Bend Radius Depends on diameter and wall thickness
Tensile Strength 210 - 360 MPa (varies by alloy)
Coating Type Uncoated or customized coating
Tolerance 0.005 mm
Flexibility Rigid
Temperature Range -196C to +400C (application dependent)
Connection Type Socket weld, Threaded, Flanged
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Non Ferrous Alloys Price And Quantity

Minimum Order Quantity 1 Piece
Price 5000.0 INR/Piece

Non Ferrous Alloys Product Specifications

Standard ASTM, DIN, BS, JIS
Temperature Range -196C to +400C (application dependent)
Flexibility Rigid
Length 1 Meter to 6 Meters or custom cut
Coating Type Uncoated or customized coating
Tolerance 0.005 mm
Shape Round
Product Type Non Ferrous Alloy Pipes
Tensile Strength 210 - 360 MPa (varies by alloy)
Section Shape Hollow
Rated Pressure As per specification
Surface Treatment Polished / Mill finished
Bend Radius Depends on diameter and wall thickness
Thickness Customized as per requirement
Thread Type BSP, NPT (where applicable)
Outer Diameter Custom range available
Application Aerospace, Plumbing, HVAC, Electrical, Marine
Usage Industrial, Engineering, Plumbing
Connection Welded / Seamless
Sealing Type Depends on connection - mechanical or welded
Diameter Standard and custom sizes
Material Grade Commercial and High conductivity grades
Color Golden / Yellowish
Yield Strength 50 - 250 MPa (varies by alloy)
Connection Type Socket weld, Threaded, Flanged
Material Copper, Brass, Bronze (Non Ferrous Alloys)

Corrosion Resistance Excellent in many industrial environments
Packaging Type Wooden boxes, Bundles, Customized packing
Conductivity Up to 97% IACS for high purity copper alloys
Inner Surface Finish Smooth, Burr-free
Machinability Good to Excellent (varies by alloy type)
Density 8.4 - 8.9 g/cm3 (material dependent)
Supply Condition Annealed / Hard / Half-Hard
Finish Availability Bright, Matte, Brushed, Pickled

Product Description

Non-ferrous alloys are metallic materials that do not contain iron as their primary base element (typically containing less than 1% iron by weight).

Because they lack iron, these alloys offer key inherent advantages over carbon and alloy steels: high corrosion resistance, non-magnetic behavior, superior electrical and thermal conductivity, low density (high strength-to-weight ratio), and ease of fabrication.

Major Non-Ferrous Alloy Families

1. Aluminum Alloys

Prized for low density (~2.7 g/cm) and high strength-to-weight ratios when alloyed and heat-treated.

Work-Hardened Series:
- 3000 Series (Al-Mn): General corrosion resistance, moderate strength (e.g., 3003, 3105).
- 5000 Series (Al-Mg): Exceptional marine/chemical resistance, high fatigue strength (e.g., 5052, 5083, 5754).
Heat-Treatable Series:
- 2000 Series (Al-Cu): High strength, aerospace structural applications (e.g., 2014, 2024).
- 6000 Series (Al-Mg-Si): Excellent extrudability, general structural (e.g., 6061-T6, 6082).
- 7000 Series (Al-Zn): Ultra-high tensile strength up to 500+ MPa (e.g., 7075-T6, 7050).

2. Copper Alloys

Chosen primarily for high thermal/electrical conductivity, biofouling resistance, and machinability.

Brasses (Cu-Zn): Cartridge brass (C26000), free-cutting brass (C36000) for threaded fittings, valving, and hardware.
Bronzes:
- Phosphor Bronze (Cu-Sn-P): High fatigue resistance for springs, bushings, and Belleville washers (e.g., C51000).
- Aluminum Bronze (Cu-Al-Fe-Ni): Exceptional wear and marine corrosion resistance (e.g., C95400, C63000).
Copper-Nickel / Cupronickel (Cu-Ni): Outstanding resistance to seawater velocity corrosion (e.g., 90/10 C70600, 70/30 C71500).

3. Nickel Alloys & Superalloys

Engineered for extreme temperature strength (creep resistance) and severely corrosive chemical processing environments.

Monel (Ni-Cu): Seawater and hydrofluoric acid resistance (e.g., Monel 400, Monel K-500).
Inconel (Ni-Cr-Fe/Mo): High-temperature oxidation resistance up to 1000C+ (e.g., Inconel 600, 625, 718).
Hastelloy (Ni-Mo-Cr): Severe acid resistance (hydrochloric, sulfuric, phosphoric) (e.g., Hastelloy C-276, C-22).

4. Titanium Alloys

Offers high strength-to-weight ratio combined with total immunity to ambient aqueous and chloride corrosion.

Commercially Pure (CP): Excellent formability and corrosion resistance (Grades 14).
Alpha-Beta Alloys: High mechanical strength (e.g., Ti-6Al-4V / Grade 5, Ti-6Al-4V ELI / Grade 23).

5. Magnesium & Zinc Alloys

Magnesium Alloys (AZ91D, AM60B): Lowest density structural metals (~1.8 g/cm), widely die-cast for automotive and aerospace housings.
Zinc Alloys (Zamak 3, Zamak 5): Precision die-casting alloys with low melting points and superior dimensional stability.

Technical Comparison Matrix

Alloy Family	Typical Density (g/cm)	Yield Strength Range (MPa)	Max Continuous Operating Temp (C)	Primary Industry / Usage
Aluminum (7000 Series)	~2.80	450 550	120 150	Aerospace, high-stress structural
Copper (Brasses/Bronzes)	~8.40 8.80	200 700	200 250	Electrical, marine fittings, bearings
Nickel Superalloys	~8.10 8.90	350 1100+	650 1000+	Gas turbines, chemical reactors, offshore
Titanium (Grade 5)	~4.43	850 1000	350 400	Aerospace, medical implants, marine
Magnesium (AZ91)	~1.81	150 220	100 120

Versatile Solutions for Industrial Use

Our non-ferrous alloy products, available in copper, brass, and bronze, are crafted to meet specific industrial requirements. With options for commercial and high-conductivity grades, you can select products tailored to your operational needs, from plumbing and HVAC systems to marine and aerospace sectors. These alloys are rigorously produced according to ASTM, DIN, BS, and JIS standards for reliable, long-term performance.

Tailored Configurations and Quality Finishes

Choose from a wide range of shapes, diameters, wall thicknesses, and finishes to suit your project requirements. Whether you need a polished, matte, brushed, or mill-finished surface, or precise tolerances down to 0.005 mm, we ensure every piece meets exacting specifications. Our materials arrive in custom packaging, guaranteeing safe delivery and easy handling.

Reliable Performance in Demanding Environments

Engineered for excellent corrosion resistance and mechanical durability, these alloys thrive in harsh industrial environments. With rated operating temperatures from -196C to +400C and various connection types (threaded, socket weld, flanged), these products are suitable for systems requiring robust, secure, and long-lasting installations.

FAQ's of Non Ferrous Alloys:

Q: How are your non-ferrous alloys packaged for safe delivery?

A: We offer packaging options such as wooden boxes, bundles, or customized solutions to protect products during transit. Each order is packed according to size, shape, and customer requirements to ensure damage-free delivery.

Q: What benefits do your copper, brass, and bronze alloys offer for industrial use?

A: Our alloys deliver high conductivity (up to 97% IACS for pure copper), superior corrosion resistance, and strong mechanical performance, making them suitable for demanding applications in electrical, marine, aerospace, plumbing, and HVAC systems.

Q: When should I opt for high-conductivity vs. commercial grade alloys?

A: High-conductivity grades are ideal for electrical and electromagnetic applications requiring maximum current flow, such as power distribution. Commercial grades suit general industrial or structural tasks where conductivity is less critical.

Q: Where can your non-ferrous alloys be applied?

A: Our products are widely used across India in sectors like electrical engineering, plumbing, HVAC, marine, and aerospace industries. They are available nationwide through an established network of suppliers, dealers, and exporters.

Q: What customization options are available for size and finish?

A: You can request custom diameters, lengths (from 1 to 6 meters or specially cut), wall thicknesses, and finishes (bright, matte, brushed, pickled, or polished). Inner and outer surface treatments and tolerances up to 0.005 mm are also customizable.

Q: How are the connections and sealing types selected for different applications?

A: Connection types-such as socket weld, threaded, flanged, welded, or seamless-are chosen based on system design, rated pressure, and application. Sealing can be mechanical or welded, ensuring compatibility with the intended use.

Q: What is the process for sourcing these alloys?

A: You can source our alloys through various authorized dealers, exporters, fabricators, manufacturers, and suppliers across India. Each product is manufactured per global standards (ASTM, DIN, BS, JIS) and can be tailored as per your specifications.
