Stainless Steel Round Pipe

Name: Stainless Steel Round Pipe
Brand: JAYANT IMPEX
Price: 300.0 INR
Availability: InStock

300.0 INR/Kilograms

Get a Price/Quote

Product Details:

Yield Strength 205 MPa min
Diameter 6 mm - 610 mm
Thread Type NPT/BSP
Tensile Strength 515 MPa min
Bend Radius Depends on diameter, typically 1.5D
Connection Type Welded, Screwed, Flanged
Flexibility Rigid
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Stainless Steel Round Pipe Price And Quantity

Minimum Order Quantity 1 Kilograms
Price 300.0 INR/Kilograms

Stainless Steel Round Pipe Product Specifications

Yield Strength 205 MPa min
Thread Type NPT/BSP
Diameter 6 mm - 610 mm
Material Grade 304, 304L, 316, 316L
Rated Pressure Up to 150 bar
Product Type Round Pipe
Outer Diameter 6 mm - 610 mm
Material Stainless Steel
Application Chemical Industry, Oil & Gas, Food Processing, Water Supply
Bend Radius Depends on diameter, typically 1.5D
Tensile Strength 515 MPa min
Shape Round
Color Silver
Connection Type Welded, Screwed, Flanged
Standard ASTM A312, A213, A269
Length Up to 6 meters (customizable)
Tolerance 0.05 mm
Flexibility Rigid
Connection Welded / Seamless
Section Shape Circular
Temperature Range -196C to 600C
Thickness 0.5 mm - 10 mm
Usage Industrial, Construction, Plumbing
Surface Treatment Polished / Mirror Finish
Sealing Type Metal-to-metal
Coating Type Uncoated

Manufacturing Process Cold Drawn or Hot Rolled
Hardness HRB 90
Lead Time 2-4 Weeks
End Finishing Plain, Beveled, Threaded
Corrosion Resistance Excellent
Packing Type Wooden Box, Bundle, Plastic Wrapping
Density 7.98 g/cm3
MOQ As per requirement
Customization Available upon request

Product Description

Here is a quick technical overview of stainless steel round pipes, broken down by grades, manufacturing types, and wall thickness standards.

Key Material Grades

Grade	Composition Highlights	Key Characteristics	Common Applications
SS 201	High Mn, lower Ni (~1%)	Low cost, moderate strength, lower corrosion resistance	Indoor furniture, handrails, decorative trim
SS 304	18% Cr, 8% Ni	Standard austenitic grade, excellent formability & general corrosion resistance	Food processing, chemical piping, water supply
SS 316	16% Cr, 10% Ni, 2-3% Mo	Added molybdenum prevents pitting corrosion from chlorides & acids	Marine fittings, pharmaceutical, offshore plants
SS 310	25% Cr, 20% Ni	High heat resistance (up to 1150C), resists oxidation	Heat exchangers, furnace parts, boiler tubes

Manufacturing Types

Seamless (SMLS): Extruded from a solid steel billet without any weld seams. Handles significantly higher internal pressure rating, ideal for boilers, high-pressure hydraulics, and critical oil & gas applications.
Welded (ERW / EFW): Formed from rolled stainless steel strip/plate and longitudinal seam welded. More cost-effective, tighter wall thickness tolerances, and suitable for structural, architectural, and moderate-pressure fluid transport.

Standard Dimensions & Wall Thickness

Pipes are specified using Nominal Pipe Size (NPS) and Schedule (Sch) per ASME B36.19M:

Wall Thickness Schedules:

Sch 5S / 10S: Light wall used primarily for sanitary tubing, HVAC, and low-pressure drainage.

Sch 40S: Standard wall general industrial fluid piping and structural applications.

Sch 80S: Extra heavy wall high-pressure environments, high vibration, or corrosive allowance.

Premium Material & Specifications

Crafted from high-quality stainless steel grades 304, 304L, 316, and 316L, our round pipes feature a density of 7.98 g/cm3, ensuring durability and resistance under demanding environments. With a hardness of HRB 90, they maintain structure under pressure and temperature extremes ranging from -196C to 600C.

Versatile Manufacturing & Finishing

Choose from cold drawn or hot rolled manufacturing processes to suit distinct application needs. End finishes including plain, beveled, and threaded options are available, as well as connections-welded, seamless, flanged, or screwed-adhering to various industrial standards and requirements.

Applications Across Industries

These pipes serve a wide range of sectors such as construction, water supply, food processing, oil & gas, and chemical industries. Their excellent corrosion resistance, polished finish, and ability to withstand up to 150 bar pressure make them reliable for transporting fluids or gases safely and efficiently.

FAQ's of Stainless Steel Round Pipe:

Q: How are the stainless steel round pipes manufactured and finished?

A: Our stainless steel round pipes are produced through either cold drawn or hot rolled processes, depending on the specification requirements. They are offered with different end finishes: plain, beveled, or threaded, to match various installation needs and standards.

Q: What industries commonly use these stainless steel round pipes?

A: These pipes are widely used in chemical industries, oil & gas, food processing, water supply, and construction. Their excellent corrosion resistance, high pressure rating, and robust material make them suitable for demanding and hygienic applications.

Q: When can I expect the delivery of my order?

A: The standard lead time for our stainless steel round pipes ranges from 2 to 4 weeks. Delivery time may vary depending on the order size, customization needs, and logistical factors.

Q: Where can these pipes be installed, and what benefits do they offer?

A: These pipes are suitable for installation in both industrial and commercial settings, particularly where resistance to corrosion and hygiene are critical. Their durability, customizability, and compliance with ASTM standards provide long-term operational benefits.

Q: What customization options are available for these pipes?

A: We offer customizations for length (up to 6 meters), outer diameter (6 mm - 610 mm), thickness (0.5 mm - 10 mm), and end finishing. Additional features such as connection types (welded, threaded, flanged) and material grades can also be tailored to your project's requirements.

Q: How are the pipes packed for transportation?

A: Our stainless steel pipes are securely packed using wooden boxes, bundled together, or wrapped in protective plastic, ensuring safe and damage-free transportation to your location across India.

Q: What standards do your stainless steel round pipes meet?

A: All pipes are manufactured in accordance with ASTM standards A312, A213, and A269, ensuring reliability, dimensional accuracy, and compliance with international quality requirements.
