DIN 1.2367 Tool Steel 2367 Round W.Nr. 1.2367 Bar

DIN 1.2367 Tool Steel 2367 Round W.Nr. 1.2367 Bar

Name: DIN 1.2367 Tool Steel 2367 Round W.Nr. 1.2367 Bar
Brand: JAYANT IMPEX
Price: 400.0 INR
Availability: InStock

400.0 INR/Piece

Get a Price/Quote

Product Details:

Length Custom / As Required
Application Hot Work Tooling, Molds, Dies, Extrusion Tools
Type Round Bar
Finish Bright, Black, Peeled or Ground
Grade 2367
Material DIN 1.2367 Tool Steel
Processing Annealed, Hardened and Tempered
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

DIN 1.2367 Tool Steel 2367 Round W.Nr. 1.2367 Bar Price And Quantity

Minimum Order Quantity 1 Piece
Price 400.0 INR/Piece

DIN 1.2367 Tool Steel 2367 Round W.Nr. 1.2367 Bar Product Specifications

Standard DIN, W.Nr. 1.2367
Technique Hot Rolled / Forged
Tolerance H9, H11 or as specified
Finish Bright, Black, Peeled or Ground
Grade 2367
Material DIN 1.2367 Tool Steel
Processing Annealed, Hardened and Tempered
Specific Use Hot Forming, Die Casting, Plastic Mold Tooling
Diameter 16mm to 400mm
Length Custom / As Required
Type Round Bar
Application Hot Work Tooling, Molds, Dies, Extrusion Tools

Max Temperature Resistance Up to 600C
Delivery State Pre-machined / Annealed
Shape Round Bar
Surface Condition Smooth, Free from Scale
Heat Treatment Quenching & Tempering possible
Impact Strength High
Density 7.85 g/cm3
Machinability Good
Hardness (Delivered Condition) 230-280 HB
Corrosion Resistance Moderate

Product Description

Werkstoffnummer (W.Nr.) 1.2367, designated under the DIN system as X38CrMoV5-3, is a premium, high-molybdenum hot-work tool steel. It is specifically engineered to outperform standard hot-work grades (like H13 or 1.2344) in applications demanding higher hot-yield strength, exceptional temper resistance, and superior resistance to thermal fatigue (heat checking).

The increased molybdenum content gives it excellent deep-hardening properties, making it highly reliable when sourced as heavy-diameter round bars.

Chemical Composition (Typical Weight %)

The high molybdenum content (Silicon (Si)

Manganese (Mn)
0.35 0.40%	2.80 3.20%	4.80 5.20%	0.50 0.70%	0.30 0.50%	0.20 0.50%

Technical Performance & Round Bar Applications

Round bars and rods of 1.2367 are typically supplied in the spheroidized annealed condition (max 230 HBW) to facilitate predictable turning, drilling, and milling. This grade is heavily utilized in high-temperature environments:

Heavy-Duty Forging Tooling: Ideal for forging die inserts, hot-punching pins, and piercer mandrels that face repeated thermal shock and extreme pressure.
Aluminum & Brass Extrusion: Specified for extrusion stems, liners, mandrels, and high-wear dies where standard 1.2344 (H13) would prematurely wear out or deform.
High-Stress Die Casting: Used for critical components in aluminum, magnesium, and zinc die-casting machines (such as shot sleeves, distribution blocks, and injection nozzles) requiring immunity to liquid-metal erosion.

Heat Treatment Specifications

1.2367 is an air-hardening steel with massive depth-of-hardness capability. To achieve optimized mechanical properties, precise heat treatment is vital:

Soft Annealing: Heat uniformly to $750^circtext{C} - 800^circtext{C}$

Global Supply Chain Equivalents

If you are cross-referencing blueprints or mill test reports (MTRs) internationally, 1.2367 sits between standard American hot-work specifications, acting as an upgraded alternative to H11/H13:

Germany (DIN / EN): X38CrMoV5-3 / W.Nr. 1.2367
United States (AISI / ASTM): Upgraded Premium H11 / Custom Hot-Work (No exact direct standard AISI equivalent, though it frequently replaces H11 and H13 for premium performance)
Russia (GOST): 4Kh5M3F (453)

Superior Performance for Hot Work Applications

DIN 1.2367 Tool Steel bars are crafted to meet the rigorous requirements of hot forming, die casting, and extrusion tools. Their high impact strength and excellent thermal stability up to 600C ensure long-lasting performance and reliability in demanding manufacturing environments. These features make them particularly suitable for repeated cycles in hot work tooling operations.

Versatile Finishes and Tailored Dimensions

Available in a range of finishes such as bright, black, peeled, or ground, our round bars are adaptable to different technical specifications. Diameters vary from 16mm to 400mm, while lengths and tolerances can be precisely customized. Such flexibility enables optimal integration with your specific project requirements.

Ready for Machining and Advanced Heat Treatment

Our 1.2367 round bars arrive pre-machined or annealed, providing good machinability for streamlined fabrication. Further enhancement via quenching and tempering is possible, allowing for tailored hardness and mechanical properties. This makes them suitable for high-stress tooling projects demanding robustness and precision.

FAQ's of DIN 1.2367 Tool Steel 2367 Round W.Nr. 1.2367 Bar:

Q: How is DIN 1.2367 Tool Steel Bar typically used in industry?

A: DIN 1.2367 Tool Steel Round Bars are primarily used in hot work tooling applications, such as for manufacturing molds, dies, extrusion tools, and plastic mold tools. Their combination of high impact strength and temperature resistance makes them ideal for high-stress environments.

Q: What benefits does this tool steel offer for hot forming operations?

A: This material provides high impact strength, good machinability, and outstanding resistance to thermal fatigue, all essential for hot forming operations. Its ability to withstand temperatures up to 600C without significant degradation adds to its reliability and longevity in production.

Q: When should quenching and tempering be applied to DIN 1.2367 Tool Steel?

A: Quenching and tempering should be carried out if higher hardness and wear resistance are needed for the specific tool application. The bars are supplied in an annealed or pre-machined state, allowing for further heat treatment as required by the end user.

Q: Where can DIN 1.2367 Round Bars be sourced and in what specifications?

A: These bars are available through authorized dealers, exporters, manufacturers, and suppliers across India. They can be supplied in diameters ranging from 16mm to 400mm, with finishes such as bright, black, peeled, or ground, and in custom lengths as specified.

Q: What is the typical process for preparing DIN 1.2367 Round Bar for use?

A: The round bars are usually delivered pre-machined and annealed, providing good machinability. For enhanced properties, further processes like quenching and tempering can be carried out to attain the desired hardness and mechanical characteristics suitable for the intended application.

Q: How does the surface condition of these bars benefit end users?

A: A smooth and scale-free surface condition minimizes the need for further surface preparation, ensuring ease of handling, improved machinability, and a reduction in wear on tooling during fabrication or service life.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Steel Bar' category

Aluminium ENAW-7075 Bars & Rods (7075-O, 7075-T6, T651) Price : 750.0 INR/Piece Minimum Order Quantity : 10 Length : 100 mm to 5000 mm Application : Aerospace, Defense, Engineering, Marine, Automobile Type : Bar & Rod Grade : 7075O, 7075T6, 7075T651 Material : Aluminium ENAW7075 Finish : Mill Finish, Polished Diameter : 6 mm to 300 mm Specific Use : Aircraft fittings, Gears, Missile parts Standard : ASTM B211, EN 573, EN 485 Processing : Precision Ground, Heat Treated Tolerance : H9, H11, H13, K12 Technique : Extruded, Cold Drawn

Send Inquiry

ASTM A182 Grade F12 Class 2 Alloy Steel F12 Round Bars Price : 100.0 INR/Kilograms Minimum Order Quantity : 1000 Length : 100 mm to 6000 mm (custom lengths available) Application : Oil and Gas Industry, Petrochemical Plants, Power Plants, High Temperature Services Type : Round Bars Grade : F12 Class 2 Material : Alloy Steel Finish : Bright, Black, Polished Diameter : 8 mm to 200 mm Specific Use : Highpressure and hightemperature service Standard : ASTM A182 Processing : Peeled, Turned, Polished Tolerance : H9, H11 or as required Technique : Hot Rolled / Forged

Send Inquiry

Alloy Steel 35C8 Round Bar 35C8 Bars 35C8 Rods Price : 169.0 INR/Kilograms Minimum Order Quantity : 1 Length : 1000mm to 6000mm or as required Application : Construction, Engineering, Industrial, Automobile Type : Round Bar, Rod, Bar Grade : 35C8 Material : Alloy Steel 35C8 Finish : Bright, Black, Polished Diameter : 6mm to 350mm Specific Use : Machinery Parts, Shafts, Pins, Fasteners Standard : IS 1875, ASTM, ASME Processing : Annealed, Hardened, Tempered Tolerance : H8, H9, or as required Technique : Hot Rolled, Cold Drawn
