BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods

BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods

210.0 INR/Kilograms
Get a Price/Quote

Product Details:

  • Standard BS 590M17
  • Processing Heat Treated, Annealed
  • Specific Use Mechanical and structural applications
  • Grade 590M17 (EN16, 1.6523)
  • Type Round Bar / Rod
  • Finish Bright / Black
  • Diameter 10mm to 300mm or as specified
  • Click to view more
Request To Call Back Send Inquiry
X

BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods Price And Quantity

  • 1 Kilograms
  • 210.0 INR/Kilograms

BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods Product Specifications

  • Bright / Black
  • h8, h9 or as specified
  • 10mm to 300mm or as specified
  • BS 590M17
  • Mechanical and structural applications
  • Heat Treated, Annealed
  • 590M17 (EN16, 1.6523)
  • Round Bar / Rod
  • Hot Rolled / Forged / Peeled
  • Custom / as required (typically 3 to 6 meters)
  • BS 590M17 Alloy Steel
  • Engineering, automotive parts, shafts, and structural components
  • Moderate
  • Mill Test Certificate as per EN10204:3.1/3.2
  • Ready Stock
  • Approx. 800 MPa
  • Approx. 560 MPa
  • Round
  • Peeled, Polished
  • Bundles or as required
  • Nickel Chromium Manganese Steel
  • 255-285 HB (Annealed)
  • Annealed / Hardened & Tempered
  • Good

Product Description

BS 590M17 (historically associated with the EN351 family or variant specifications under BS 970) is a low-alloy, chromium-manganese case-hardening (carburizing) steel. It is widely supplied as round bars, rods, and blocks for engineering applications that require a highly wear-resistant surface coupled with a tough, ductile core.

Here is a technical overview of its specifications, international equivalents, chemical composition, and typical mechanical profiles.

Technical Specifications & Cross-References

When cross-referencing global standards to source equivalent round bars, the closest matches include:

Standard Designation / Grade
British Standard (BS 970) 590M17 / 527M17
European (EN / DIN / WNr) 16MnCr5 / 1.7131
AISI / SAE (USA) 5115 / 5117
AFNOR (France) 16MC5
GOST (Russia) 18KhG (18) / 15HG
JIS (Japan) SCr415

Chemical Composition

The performance of 590M17 relies on a controlled balance of manganese and chromium to optimize hardenability during case hardening.

  • Carbon (C): 0.14% 0.19% (low carbon allows the core to remain tough after quenching)

  • Manganese (Mn): 1.00% 1.30%

  • Chromium (Cr): 0.80% 1.10%

  • Silicon (Si): max. 0.40%

  • Phosphorus (P): max. 0.035%

  • Sulfur (S): max. 0.035% (enhanced machinability variants may feature controlled higher sulfur)

Key Mechanical Properties & Characteristics

Because it is a case-hardening grade, its final mechanical properties depend highly on the heat treatment (carburizing, quenching, and tempering).

  • Hardenability: It offers low-to-medium core hardenability. It is optimized for maintaining structural core toughness in small-to-medium section sizes (typically up to 20 mm to 50 mm ruling sections).

  • Core Tensile Strength: Typically around 7001000 MPa post-heat treatment, depending on diameter.

  • Supply Condition: Commonly supplied in the As-Rolled,Normalized, or Soft Annealed (max. 207 HBW) state to maximize precision and tool life during initial machining.

Core Applications

Due to its excellent forgeability, response to carburizing, and balanced machinability (approx. 80% of mild steel), 590M17 round bars are heavily utilized in power transmission and heavy-duty clamping hardware:

  • Gears and Pinions: Severe surface wear resistance with high shock resistance.

  • Shafts and Camshafts: Excellent performance under cyclic fatigue.

  • Heavy Clamping & Fasteners: Specialized joint components, gudgeon pins, and heavy-duty bolts requiring localized wear resistance.



Superior Mechanical Properties

These BS 590M17 round bars exhibit excellent strength, with a yield strength near 560 MPa and an ultimate tensile strength around 800 MPa. Their good machinability makes them suitable for components requiring intricate fabrication, like shafts and engineering parts.


Flexible Sizing and Finishing Options

With custom lengths (typically 3 to 6 meters) and a diameter range from 10mm to 300mm, these bars are manufactured using hot rolled, forged, or peeled techniques. The surface condition can be peeled or polished, providing bright or black finishes as per project requirements.


Certified Quality and Readily Available

Every bar is supplied with a Mill Test Certificate according to EN10204:3.1/3.2. Stock is readily available, and packaging can be customized in bundles or as specified, ensuring prompt delivery for projects.

FAQ's of BS 590M17 Alloy Steel Bar 590M17 Round Bars 590M17 Rods:


Q: How is the BS 590M17 Alloy Steel Bar commonly used?

A: The BS 590M17 Alloy Steel Bar is widely utilized in engineering, automotive, and mechanical industries, particularly for shafts, structural parts, and components demanding high strength and good machinability.

Q: What certifications do BS 590M17 bars come with?

A: Each bar is accompanied by a Mill Test Certificate as per EN10204:3.1 or 3.2, ensuring the product's chemical composition and mechanical properties meet the specified standards.

Q: When are these alloy steel bars delivered and in what condition?

A: Delivery is prompt due to ready stock availability. Depending on application needs, bars are delivered either in annealed or hardened & tempered conditions.

Q: Where can I source BS 590M17 alloy steel bars?

A: These bars are available throughout India via dealers, exporters, fabricators, manufacturers, and suppliers offering various diameters, lengths, and finishes required for your projects.

Q: What machining and finishing options are offered for these bars?

A: BS 590M17 bars provide good machinability and can be supplied with bright, black, peeled, or polished surface finishes. Dimensional tolerances such as h8 or h9 can be specified to match project requirements.

Q: What are the benefits of using BS 590M17 bars in construction?

A: These alloy steel bars offer high strength, reliable machinability, moderate corrosion resistance, and the ability to be heat treated, making them ideal for mechanical and structural applications demanding durability.

Q: What process is used to manufacture BS 590M17 alloy steel rods?

A: The bars are manufactured using hot rolling, forging, or peeling processes, followed by heat treatment (annealing or quenching and tempering) to achieve the desired mechanical properties.
