Mould Steel Bars

Name: Mould Steel Bars
Brand: JAYANT IMPEX
Price: 615.0 INR
Availability: InStock

615.0 INR/Kilograms

Get a Price/Quote

Product Details:

Width Varies as per requirement
Size Customizable as per order
Corrosion Resistant Moderate, can be improved by surface treatment
Chemical Composition Common mould steel compositions such as C, Mn, Si, Cr, Ni, Mo (Details upon request)
Temper Annealed or as rolled
Recyclable Yes
Product Form Bar
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Mould Steel Bars Price And Quantity

Minimum Order Quantity 1 Kilograms
Price 615.0 INR/Kilograms

Mould Steel Bars Product Specifications

Application Tooling, Machinery, Mould Manufacturing
Finish Type Mill or as specified
Surface Rough / Scaled / Mill finish
Recyclable Yes
Shape Rectangular / Flat Bar
Steel Type Alloy Steel / Carbon Steel (Subject to grade)
Product Form Bar
Material Grade As per customer requirement
Coating Type None / Can be customized
Dimension (L*W*H) Custom sizes available
Color Metallic Grey
Diameter Not applicable (Rectangular / Flat Bar)
Product Name Mould Steel Bars
Heat Resistance Yes
Tensile Strength Typically 900 - 1200 MPa (grade-dependent)
Material Composition % Provided with test certificate
Hardness 28 - 50 HRC (grade-dependent)
Width Varies as per requirement
Steel Standard ASTM, DIN, JIS or as per order
Grade P20, H13, D2, or as specified
Composition Varies depending on grade and application
Steel Product Type Bars
Size Customizable as per order
Corrosion Resistant Moderate, can be improved by surface treatment
Chemical Composition Common mould steel compositions such as C, Mn, Si, Cr, Ni, Mo (Details upon request)
Weight Based on dimension and grade
Temper Annealed or as rolled
Thickness Varies, typically 10 mm onwards
Usage Mould base, dies, industrial tooling

Packaging Type Bundled or as required
Machinability Good, grade-specific
Custom Shapes Available on request
Test Certificate Available upon request
Lead Time 2-4 weeks typically
Thermal Conductivity Grade-dependent, information on request
Stock Availability Ready stock or as per order
Edge Condition Square cut / Mill edge
Magnetic Properties Magnetic
MOQ Negotiable
Delivery Condition Black / Annealed / Machined

Product Description

Material Classification and Cross Reference

Material Designation	Alloy Family	Primary Form	Application Method	Equivalent Standard
DIN 1.2316	Martensitic Stainless Tool Steel	Hot Rolled Forged Round Bar	Machining Precision EDM Polishing	EN ISO 4957 X38CrMo16
DIN X36CrMo17	Martensitic Stainless Tool Steel	Flat Bar Forged Block	Deep Cavity Injection Moulding	DIN 17350 Standard Grade
AISI 420F Modified	High Chromium Stainless Tool Steel	Turned Peeled Round Bar	CNC Milling Slotting Turning	ASTM A681 USA Grade
JIS SUS420J2 Modified	High Chromium Stainless Tool Steel	Precision Ground Flat Plate	Mirror Finish Mould Tooling	JIS G4303 Japanese Standard

Nominal Chemical Composition

Element	Element Name	Minimum Mass Fraction	Maximum Mass Fraction	Nominal Value
Fe	Iron	Balance	Balance	79.40
Cr	Chromium	15.50	17.50	16.50
Mo	Molybdenum	0.80	1.30	1.05
C	Carbon	0.33	0.45	0.38
Mn	Manganese	0.00	1.00	0.60
Si	Silicon	0.00	1.00	0.50
Ni	Nickel	0.00	1.00	0.50
P	Phosphorus	0.00	0.03	0.015
S	Sulfur	0.00	0.03	0.015

Physical and Mechanical Properties

Property	Value Range	Metric Units	Imperial Units
Density	7.70	Grams per Cubic Centimeter	0.278 Pounds per Cubic Inch
Hardness Pre Hardened	28 to 32	Rockwell C	Rockwell C
Hardness Quenched and Tempered	48 to 52	Rockwell C	Rockwell C
Tensile Strength Ultimate	950 to 1100	Megapascals	138000 to 160000 Pounds per Square Inch
Yield Strength	800 to 920	Megapascals	116000 to 133000 Pounds per Square Inch
Modulus of Elasticity	215	Gigapascals	31200000 Pounds per Square Inch
Thermal Conductivity at 20 Celsius	18 to 20	Watts per Meter Kelvin	125 to 138 BTU Inch per Hour Square Foot Fahrenheit
Thermal Expansion Coefficient	10.5 to 12.0	Micrometers per Meter Kelvin	5.83 to 6.67 Microinches per Inch Fahrenheit
Maximum Service Temperature	400	Celsius	752 Fahrenheit

Versatile Grades & Dimensions

Mould Steel Bars are offered in multiple grades like P20, H13, and D2, with personalized dimensions to meet specific project requirements. Choose from rectangular or flat bars in various thicknesses, finishing, and edge conditions. Custom sizes and shapes are available, catering to a diverse set of tooling, mould making, and machinery applications.

Reliable Certification & Quality Assurance

Each batch of Mould Steel Bars comes with a test certificate detailing the chemical composition and material properties, ensuring compliance and quality. Supplied by reputable dealers, exporters, manufacturers, and suppliers in India, customers can request certification and technical details for assured product integrity.

Flexible Supply and Fast Lead Times

The product is available from ready stock or can be manufactured as per your order, accommodating urgent as well as planned project schedules. Standard lead times range from 2 to 4 weeks, with negotiation possible on order quantity and packaging tailored to your needs.

FAQ's of Mould Steel Bars:

Q: How are Mould Steel Bars typically delivered and what are the available conditions?

A: Mould Steel Bars can be supplied in black, annealed, or machined conditions depending on your requirements. Edges can be provided as square cut or with a mill edge, and packaging is available as bundled or customized upon request.

Q: What is the minimum order quantity (MOQ) for these steel bars?

A: The minimum order quantity for Mould Steel Bars is negotiable, allowing flexibility for both small and large-scale orders to suit various project sizes.

Q: When can I expect delivery of my Mould Steel Bar order?

A: Typical lead time for Mould Steel Bars is between 2 and 4 weeks. If the required specifications are available in ready stock, delivery may be expedited. Custom orders may require additional production time.

Q: Where can I obtain the chemical composition and material test certificate?

A: Upon request, a test certificate providing detailed chemical composition (including elements like C, Mn, Si, Cr, Ni, Mo) and mechanical properties is furnished with your order to assure quality and traceability.

Q: What is the process for custom shapes and sizes?

A: Custom dimensions and shapes are produced as per customer instructions. Simply provide your dimensional and shape requirements when inquiring or placing an order, and the bars will be fabricated accordingly, subject to technical feasibility.

Q: How are these bars used in industry, and what benefits do they offer?

A: Mould Steel Bars are widely used in tooling, die-making, and mould manufacturing due to their good machinability, reliable heat resistance, and moderate corrosion resistance. Their customizable sizes and grades make them highly versatile for industrial applications.

Q: What are the packaging and edge type options available for these steel bars?

A: Packaging is typically bundled, but can be modified as per your requirements. Edge conditions can be supplied as square cut or mill edge based on application needs and customer preference.
