Alloy Pipe

Name: Alloy Pipe
Brand: JAYANT IMPEX
Price: 255555.0 INR
Availability: InStock

255555.0 INR/Ton

Get a Price/Quote

Product Details:

Diameter Customizable as per requirement
Connection Type Butt Weld, Socket Weld, Threaded
Tensile Strength 550-700 MPa
Thread Type NPT, BSP, Metric (if applicable)
Coating Type Oil Coated, Black Painted, Galvanized (if required)
Bend Radius Standard or Custom as required
Tolerance 0.05 mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Alloy Pipe Price And Quantity

Price 255555.0 INR/Ton
Minimum Order Quantity 1 Ton

Alloy Pipe Product Specifications

Tolerance 0.05 mm
Yield Strength 300-480 MPa
Connection Welded/Seamless
Material Alloy Steel
Section Shape Round
Application Oil & Gas, Petrochemical, Power Generation, Construction
Coating Type Oil Coated, Black Painted, Galvanized (if required)
Bend Radius Standard or Custom as required
Flexibility Rigid
Temperature Range -40C to 600C
Surface Treatment Polished
Thickness 2 mm - 50 mm (customizable)
Usage Industrial, Engineering, Mechanical, Structural Applications
Sealing Type Metal to Metal/Seal Welding
Outer Diameter 10 mm - 600 mm
Thread Type NPT, BSP, Metric (if applicable)
Rated Pressure As per specification
Product Type Alloy Pipe
Material Grade Alloy 4130, 4140, 15Mo3, 16Mo3, T11, T22, and other grades
Diameter Customizable as per requirement
Connection Type Butt Weld, Socket Weld, Threaded
Color Metallic Grey
Tensile Strength 550-700 MPa
Length Random, Fixed, Cut Length or as required
Shape Round
Standard ASTM, DIN, JIS, EN, IS

Minimum Order Quantity As per client requirement
End Finish Plain End, Beveled End, Threaded End
Testing Hydrostatic, Ultrasonic, Eddy Current, Visual and Dimensional Test
Corrosion Resistance Excellent due to alloy content
Pipe Weight As per size and thickness
Production Technique Cold Drawn, Hot Rolled, Seamless, Welded
Packaging Bundles with steel strips, Plastic caps on ends, Wrapped in HDPE Sheets

Product Description

Alloy steel pipes are made by combining carbon steel with alloying elements such as chromium, molybdenum, nickel, and vanadium to improve mechanical properties like tensile strength, heat resistance, and corrosion resistance.

Categories & Manufacturing Types

Low-Alloy Steel Pipes: Contain less than 5% alloying elements. They offer a balance between high strength, good weldability, and cost efficiency.
High-Alloy Steel Pipes: Contain more than 5% alloying elements. These include high-chromium steels and nickel alloys designed for extreme environments.
Seamless Pipes: Extruded from solid steel billets without any weld seams, providing superior pressure resistance and strength for critical high-temperature/high-pressure applications.
Welded Pipes: Fabricated by welding rolled plates or coils, offering a cost-effective option for low- to medium-pressure applications.

Common Industrial Grades

ASTM A335 Grade P11 / P22 (Chrome-Moly): Standard alloy pipes for power generation, boilers, and refineries operating at elevated temperatures.
ASTM A335 Grade P91: High-strength 9% Chromium, 1% Molybdenum steel for high-pressure steam lines and critical thermal power systems.
AISI 4130 / 4140: High-tensile, wear-resistant structural tubing widely used in aerospace, automotive, machine components, and oilfield equipment.

Quality Manufacturing Process

Our alloy pipes are produced using advanced cold drawn, hot rolled, seamless, or welded techniques. Every batch is thoroughly tested-hydrostatics, ultrasonic, eddy current, visual, and dimensional assessments-to guarantee integrity and conformity to diverse global standards. Flexible options in finishing and surface treatments enhance usability in demanding environments.

Customizable Options

Alloy pipes are highly customizable in terms of diameter (10 mm to 600 mm), thickness (2 mm to 50 mm), length, and surface treatment. With a selection of end finishes like plain, beveled, or threaded ends and a choice of metal grades such as Alloy 4130, 4140, 15Mo3, and T11, these pipes are tailored to meet each project's specific technical requirements.

Extensive Industrial Usage

Engineered for superior performance in oil & gas, petrochemical, power generation, and construction industries, our pipes withstand temperatures from -40C to 600C and rated pressures as specified. With excellent corrosion resistance, they ensure long-lasting service in harsh industrial environments and various mechanical and structural applications.

FAQ's of Alloy Pipe:

Q: How are alloy pipes tested for quality and reliability?

A: Our alloy pipes undergo multiple rigorous tests, including hydrostatic, ultrasonic, eddy current, visual, and dimensional inspections. These processes help ensure the pipes meet international standards like ASTM, DIN, JIS, EN, and IS, verifying both structural integrity and dimensional accuracy.

Q: What customization options are available for alloy pipes?

A: You can customize the pipes' outer diameter (10 mm-600 mm), thickness (2 mm-50 mm), length, and end finish (plain, beveled, threaded). Also, different material grades and surface treatments such as oil coating, black painting, or galvanizing are available to match your project needs.

Q: When should I choose hot rolled or cold drawn pipes?

A: Cold drawn pipes are recommended for applications demanding higher dimensional precision and smooth surface finishes, while hot rolled pipes are ideal when strength and cost-efficiency are primary considerations in structural or mechanical settings.

Q: Where are these alloy pipes most commonly used?

A: These pipes are suitable for a wide range of industries including oil & gas, petrochemical, power generation, construction, and general engineering. Their excellent corrosion resistance and mechanical strength make them a preferred choice for environments exposed to harsh conditions.

Q: What are the benefits of the different end finishes offered?

A: Plain ends are suitable for welding, beveled ends facilitate easier butt welding, and threaded ends are ideal for quick assembly in piping systems. The choice depends on the installation method and connection requirements of your application.

Q: How are the pipes packaged and protected during delivery?

A: Pipes are bundled with steel strips, capped with plastic ends, and wrapped in HDPE sheets to prevent corrosion and physical damage during transit, ensuring the product reaches you in optimal condition.

Q: What is the minimum order quantity for custom alloy pipes?

A: We accommodate orders based on your specific requirements, so the minimum order quantity is flexible and defined according to the project or client's needs.
