5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods 5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods 5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods 5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods 5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods

5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods

575.0 INR/Piece
Get a Price/Quote

Product Details:

  • Surface Treatment Bright / Mill Finish
  • Diameter 1.6 mm, 2.0 mm, 2.4 mm, 3.2 mm, 4.0 mm
  • Corrosion Resistant Yes
  • Finish Bright
  • Thickness As per customer requirement
  • Grade 5183 - AlMg4.5Mn0.7A
  • Feature Excellent corrosion resistance, High strength, Good weldability
  • Click to view more
Request To Call Back Send Inquiry
X

5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods Price And Quantity

  • 575.0 INR/Piece
  • 50 Piece

5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods Product Specifications

  • Excellent corrosion resistance, High strength, Good weldability
  • Minimum 275 MPa
  • Round Rod
  • 60-65 HRB
  • 0.05 mm
  • Rod
  • AWS A5.10 / ASME SFA5.10 ER5183
  • Depends on weld design
  • Custom as per order
  • Bright / Mill Finish
  • Welding of Aluminium-Magnesium alloys, Marine structures, Storage tanks, Railway wagons
  • 1.6 mm, 2.0 mm, 2.4 mm, 3.2 mm, 4.0 mm
  • Bright
  • Filler Rod
  • Yes
  • 5183 - AlMg4.5Mn0.7A
  • As per customer requirement
  • Aluminium Alloy
  • 12% minimum
  • Unlimited (If stored properly)
  • Good thermal and electrical conductivity
  • Solid Wire Rod
  • 2.66 g/cm3
  • Silvery
  • Plastic Tube, Bundle
  • 570-640C

Product Description

EN AW-5183 (S Al 5183 / AlMg4.5Mn0.7) is a premium aluminum-magnesium-manganese welding consumable available in continuous spools for MIG (GMAW) welding and cut straight lengths for TIG (GTAW) welding.

Engineered specifically to match the high tensile and yield strength requirements of structural 5xxx-series alloys (particularly EN AW-5083), it provides significantly higher as-welded joint strength than standard ER5356 or ER4043 wire.

Chemical Composition (EN ISO 18273 / AWS A5.10)

  • Magnesium (Mg): 4.30 to 5.20 percent

  • Manganese (Mn): 0.50 to 1.00 percent

  • Chromium (Cr): 0.05 to 0.25 percent

  • Titanium (Ti): 0.15 percent maximum

  • Iron (Fe): 0.40 percent maximum

  • Silicon (Si): 0.40 percent maximum

  • Zinc (Zn): 0.25 percent maximum

  • Copper (Cu): 0.10 percent maximum

  • Aluminum (Al): Balance

Mechanical and Thermal Properties (As-Welded)

  • Tensile Strength: 275 MPa minimum (40 ksi)

  • Yield Strength: 130 MPa minimum (19 ksi)

  • Elongation: 17 percent minimum

  • Melting Range: 574 to 638 degrees Celsius

  • Anodizing Match: Excellent silver and white color match with 5xxx base metals

Typical Applications and Technical Considerations

  • Primary Marine and Industrial Uses: Shipbuilding hulls, offshore oil platforms, LNG tank storage, high-stress pressure vessels, railway cars, and heavy structural frames.

  • Base Metal Matching: Ideal for joining EN AW-5083, EN AW-5086, EN AW-5456, and EN AW-7039.

  • Shielding Gas Recommendations:

    • TIG (GTAW): 100 percent Argon (I1)

    • MIG (GMAW): 100 percent Argon or Argon/Helium mixtures (I3) for improved penetration on plate thicknesses over 6 mm.

Temperature Warning: Because the magnesium content exceeds 3.0 percent, welds made using EN AW-5183 are susceptible to stress corrosion cracking if operated in continuous service temperatures exceeding 65 degrees Celsius (150 degrees Fahrenheit).

Standard Product Forms and Standards

  • EN ISO 18273: S Al 5183 / AlMg4.5Mn0.7(A)

  • AWS A5.10 / ASME SFA-5.10: ER5183 (MIG) / R5183 (TIG)

  • WNr / DIN 1732: 3.3548 / SG-AlMg4.5Mn

  • Available Delivery Forms:

    • MIG Wire: 0.8 mm, 1.0 mm, 1.2 mm, and 1.6 mm spools (D200, D300, K300)

    • TIG Rods: 1.6 mm, 2.0 mm, 2.4 mm, 3.2 mm, and 4.0 mm cut lengths (1000 mm)



Superior Performance for Demanding Applications

Engineered with exceptional mechanical and chemical properties, 5183 - AlMg4.5Mn0.7A wire rods deliver high strength and corrosion resistance, making them suitable for challenging environments. With good thermal and electrical conductivity, they serve critical roles in marine construction, storage tanks, and railway components. Choosing these rods ensures robust, long-lasting welds even under harsh conditions.


Flexible Options and Custom Capacities

These filler rods are offered in various diameters (1.6 mm to 4.0 mm) and can be supplied in plastic tubes or bundles, with custom order capacities to match project specifications. The rods' tolerance of 0.05 mm and customizable thicknesses ensure precise fit for diverse welding needs, making them a reliable choice for manufacturers, exporters, and fabricators across India.

FAQ's of 5183 - AlMg4.5Mn0.7A Aluminium Alloy Filler Metal Wire Rods:


Q: How should 5183 - AlMg4.5Mn0.7A filler rods be stored to maintain shelf life?

A: These rods should be stored in a dry, clean environment and kept in their original plastic tube or bundle packaging. Proper storage prevents contamination and ensures an unlimited shelf life.

Q: What applications are ideal for using 5183 - AlMg4.5Mn0.7A aluminium alloy wire rods?

A: They are commonly used for welding aluminium-magnesium alloys, particularly in marine structures, storage tanks, and railway wagons due to their excellent corrosion resistance and strength.

Q: When is it beneficial to choose this alloy over other filler metals?

A: Select this alloy when working with 5XXX-series aluminium alloys, especially if high strength, enhanced corrosion resistance, and good weldability are required for the project.

Q: Where can 5183 - AlMg4.5Mn0.7A rods be purchased in India?

A: These rods are available from various suppliers, manufacturers, exporters, and dealers throughout India, catering to both industrial and fabrication needs.

Q: What is the recommended welding process for these filler metal rods?

A: 5183 - AlMg4.5Mn0.7A wire rods are designed for use with MIG and TIG welding processes, providing strong, high-quality welds on aluminium-magnesium alloys.

Q: How does using this product benefit my welding projects?

A: Utilizing this filler rod ensures excellent joint strength, high resistance to corrosion, and reliable weld quality, especially in structures exposed to harsh environments.

Q: What diameters are available, and can I request custom sizes?

A: Standard diameters range from 1.6 mm to 4.0 mm, but custom capacities and thicknesses can be arranged to meet specific project requirements.
