Tribaloy T-800, B50TF193, DMR 34.071, PMET 980 Scra

Tribaloy T-800, B50TF193, DMR 34.071, PMET 980 Scra

Name: Tribaloy T-800, B50TF193, DMR 34.071, PMET 980 Scra
Brand: JAYANT IMPEX
Price: 15000.0 INR
Availability: InStock

15000.0 INR/Piece

Get a Price/Quote

Product Details:

Diameter As per customer requirement
Temperature Range Up to 900C (approximate, depending on application)
Thread Type N/A (typically unthreaded)
Sealing Type As required (typically metal-to-metal)
Flexibility Rigid
Tensile Strength ~930 MPa (Typical for Tribaloy T-800)
Coating Type None / As specified
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Tribaloy T-800, B50TF193, DMR 34.071, PMET 980 Scra Price And Quantity

Price 15000.0 INR/Piece
Minimum Order Quantity 1 Piece

Tribaloy T-800, B50TF193, DMR 34.071, PMET 980 Scra Product Specifications

Standard As per customer specification / DMR 34.071
Diameter As per customer requirement
Connection Press fit / Interference fit / Custom
Temperature Range Up to 900C (approximate, depending on application)
Outer Diameter As per drawing / Custom
Thread Type N/A (typically unthreaded)
Color Metallic grey
Application Aerospace, marine, industrial, power plant, chemical processing
Surface Treatment None / As required
Material Tribaloy T-800 (B50TF193 / DMR 34.071 / PMET 980)
Sealing Type As required (typically metal-to-metal)
Shape Cylindrical
Thickness Custom / As per drawing
Flexibility Rigid
Tensile Strength ~930 MPa (Typical for Tribaloy T-800)
Length As per requirement / Custom
Product Type Bush / Sleeve / Liner / Ring (As per requirement)
Coating Type None / As specified
Tolerance Close tolerance as per drawing/specification
Section Shape Round
Material Grade Tribaloy T-800
Yield Strength ~475 MPa (Typical for Tribaloy T-800)
Usage Wear, corrosion, high temperature resistance applications
Connection Type Sleeve / Bush insertion / Custom
Rated Pressure N/A (Dependent on system design)

Microstructure Cobalt-based alloy with Laves phase (provides superior wear resistance)
Manufacturing Process Centrifugally cast / Machined to final dimensions
Hardness 56-62 HRC (as cast)
Corrosion Resistance Excellent against low and high temperature oxidation and corrosion
Density 8.4 g/cm3 (approximate)
Heat Resistance Maintains hardness & strength up to 900C
Wear Resistance Exceptional, suitable for abrasive and erosive environments
Machinability Difficult, requires special cutting tools and techniques

Product Description

Material Classification and Cross Reference

Material Designation	Alloy Family	Primary Form	Application Method	Equivalent Standard
Tribaloy T-800	Cobalt Molybdenum Chromium Silicon	Solid Cast Wrought PM	Casting Machining PM Sintering	UNS R30800 SAE Tribaloy T-800
B50TF193	Cobalt Molybdenum Chromium Silicon	Aerospace Casting Hardfacing	Investment Casting PTA Weld Overlay	GE Aviation Specification
DMR 34.071	Cobalt Molybdenum Chromium Silicon	Hardfacing Consumable Solid	Plasma Arc Welding Hardfacing	Safran Snecma Specification
PMET 980	Cobalt Molybdenum Chromium Silicon	Solid Hardfacing Wire Powder	Automated TIG Laser Cladding	Polymet T-800 Equivalent Wire

Nominal Chemical Composition

Element	Element Name	Minimum Mass Fraction	Maximum Mass Fraction	Nominal Value
Co	Cobalt	Balance	Balance	52.00
Mo	Molybdenum	27.00	30.00	28.50
Cr	Chromium	16.50	18.50	17.50
Si	Silicon	3.00	3.80	3.40
C	Carbon	0.00	0.08	0.04
Fe Ni	Iron and Nickel Combined	0.00	3.00	1.50

Physical and Mechanical Properties

Property	Value Range	Metric Units	Imperial Units
Density	8.63	Grams per Cubic Centimeter	0.312 Pounds per Cubic Inch
Deposit Hardness	52 to 62	Rockwell C	Rockwell C
Hot Hardness at 800 Celsius	45 to 50	Rockwell C	Rockwell C
Melting Point Minimum	1290	Celsius	2354 Fahrenheit
Melting Point Maximum	1400	Celsius	2552 Fahrenheit
Maximum Service Temperature	800	Celsius	1472 Fahrenheit
Ultimate Tensile Strength	480 to 700	Megapascals	70000 to 102000 Pounds per Square Inch

Engineered for Demanding Environments

Tribaloy T-800 excels where conventional alloys falter. Its Laves phase-rich cobalt matrix withstands intense wear and oxidation, ensuring long-term operation at high temperatures. Customizable dimensions and tolerances make it highly versatile for varied industries including aerospace, marine, and chemical processing. Designed for harsh applications, it supports press fit, interference fit, or custom insertions.

Superior Resistance to Corrosion and Wear

This alloy provides excellent corrosion resistance, even at elevated temperatures. Its structure ensures durability not only against oxidation but also against abrasive and erosive forces. Tribaloy T-800's outstanding performance minimizes downtime and maintenance for critical systems operating in some of the most challenging industrial environments.

Precision Manufacturing & Customization

Produced through centrifugal casting and precision machining, each piece is tailored to specific client needs. Close tolerances according to drawings and customer specifications ensure a seamless fit and reliable function. Surface treatment and connection types are available upon request, supporting a variety of engineering applications.

FAQ's of Tribaloy T-800, B50TF193, DMR 34.071, PMET 980 Scra:

Q: How is Tribaloy T-800 manufactured and finished?

A: Tribaloy T-800 is produced using centrifugal casting, followed by precise machining to achieve custom dimensions and close tolerances as specified in customer drawings. Surface treatments and additional finishing can be applied as required.

Q: What makes Tribaloy T-800 suitable for high-temperature applications?

A: The alloy retains high strength and hardness-measuring 56-62 HRC-even at temperatures up to 900C. Its cobalt-based Laves phase structure ensures superior thermal stability, making it ideal for applications in aerospace, power plants, and chemical processing.

Q: Where can Tribaloy T-800 components be used effectively?

A: Tribaloy T-800 is utilized in environments requiring outstanding wear and corrosion resistance, such as aerospace systems, marine components, industrial machinery, power generation, and chemical processing equipment.

Q: What are the machining challenges associated with Tribaloy T-800?

A: Due to its exceptional hardness and wear resistance, machining Tribaloy T-800 is difficult and requires the use of specialized cutting tools and techniques. Experience with hard alloys is recommended to achieve the desired finish and tolerance.

Q: What are the main benefits of using Tribaloy T-800?

A: The primary benefits include excellent resistance to abrasion, erosion, and corrosion, stability at high temperatures, long component life, and reliable performance under extreme operating conditions.

Q: When should Tribaloy T-800 be chosen over other alloys?

A: Tribaloy T-800 should be selected when applications demand a combination of intense wear resistance, high-temperature strength, and superior corrosion resistance-particularly in challenging, abrasive, or oxidizing environments.
