Taper Washers

200 INR/Piece

Get a Price/Quote

Product Details:

Usage I Beams, U Beams, Channel Section, Bolt Supports
Material Carbon Steel, Stainless Steel 304, Stainless Steel 304L, Stainless Steel 316, Stainless Steel 316L, Mild Steel
Shape Square, Tapered
Size M4-M36
Height Multiple Millimeter (mm)
Product Type Taper Washer
Thickness Multiple Millimeter (mm)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Taper Washers Price And Quantity

Price Range 200.00 - 500.00 INR/Piece
Price 200 INR/Piece
Minimum Order Quantity 10 Piece

Taper Washers Product Specifications

Color Natural Finish
Thickness Multiple Millimeter (mm)
Surface Treatment Black Phosphated, Natural Finish, Hot Dip Galvanized, Zinc Plated
Length NA Millimeter (mm)
Height Multiple Millimeter (mm)
Material Carbon Steel, Stainless Steel 304, Stainless Steel 304L, Stainless Steel 316, Stainless Steel 316L, Mild Steel
Width Multiple Millimeter (mm)
Product Type Taper Washer
Weight Gram Grams (g)
Application I Beams, U Beams, Channel Section, Nuts &Bolt Supports
Standard DIN 434, IS 5372, IS 5374, CSN 021739, PN 82018, UNI 6598
Usage I Beams, U Beams, Channel Section, Bolt Supports
Shape Square, Tapered
Size M4-M36

Taper Washers Trade Information

FOB Port Nhava Sheva
Payment Terms Cash Advance (CA), Cash in Advance (CID), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)
Sample Available Yes
Sample Policy Within a certain price range free samples are available
Packaging Details Corrugatex Boxes, Gunny Bags
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India
Certifications ISO:9001

Product Description

Jayant Taper Washers are designed to be used on channel sections, underneath nuts with Taper flanges to enable the bolt assembly to fit square/level when tightened fastened.These washers are mainly used to correct alignments in structures and ensure that the parallelism is consistent throughout the product.

Size Range : M4-M30

Grade : Carbon Steel, Mild Steel, Stainless Steel 304, Stainless Steel 316L

We also Manufacture as per Customers Requirement

Versatility in Structural Applications

Taper washers serve a crucial purpose in connecting structural steel members like I beams, U beams, and channel sections, providing aligned, level surfaces for bolts and nuts. Their design caters to a wide range of sizes and thicknesses, making them suitable for various engineering and construction projects where precise load distribution is essential.

Robust Materials and Surface Treatments

Produced from robust materials including carbon steel and multiple grades of stainless steel, taper washers offer excellent durability and corrosion resistance. With surface treatments such as black phosphating, hot dip galvanization, and zinc plating, they are resilient against harsh working environments and maintain structural integrity over time.

FAQs of Taper Washers:

Q: How are taper washers typically used in construction?

A: Taper washers are commonly used with bolts and nuts to compensate for non-parallel surfaces in steel structures, such as I beams and channel sections. They ensure the bolt load is distributed evenly, enhancing the stability and safety of structural joints.

Q: What materials and finishes are available for taper washers?

A: These washers are manufactured from carbon steel, mild steel, and several stainless steel grades (304, 304L, 316, 316L). Surface treatments include black phosphated, hot dip galvanized, and zinc-plated finishes, which help improve corrosion resistance and durability.

Q: When should I use a tapered rather than a flat washer?

A: A tapered washer should be used when the bearing surfaces of the connected components are not parallel, such as with channels or I beams, to prevent bolt bending and ensure proper clamping force between structural elements.

Q: Where do taper washers comply with standard specifications?

A: Taper washers used in structural applications comply with international standards including DIN 434, IS 5372, IS 5374, CSN 021739, PN 82018, and UNI 6598, ensuring consistency and reliability in performance for engineering projects.

Q: What is the process for selecting the correct size of taper washer?

A: To select the appropriate taper washer, consider the bolt size (ranging from M4 to M36), the required thickness, and the applications specific requirements. Matching the washers slope and size to the angle of the surface ensures optimal function.

Q: What are the benefits of using taper washers for bolt support?

A: Taper washers provide a stable and uniform platform for fasteners on angled structures, reduce bolt fatigue, enhance joint strength, and increase the lifespan of assemblies subjected to dynamic loads or vibration.
