5154A - AlMg3.5A Aluminium Plates, Sheets, Blocks(DIN, WNr)

Product Description

5154A (AlMg3.5A) is a high-grade aluminum-magnesium alloy that sits between the standard 5754 and the high-strength 5083. The "A" suffix in the European designation indicates a specific variation of the chemical composition aimed at optimizing weldability and ductility.

It is frequently specified for components that require a higher strength profile than AlMg3 but still need to maintain excellent formability.

Equivalent Designations

• DIN/WNr: AlMg3.5A / 3.3536

• EN: EN AW-5154A

• ISO: AlMg3.5

• Old British Standard: N5

---

Comparison: 5154A vs. 5754 and 5454

While they all share the "AlMg" family tree, 5154A has a higher Magnesium content ($3.1% - 3.8%$), which shifts its performance:

• Strength: It is stronger than 5754 (AlMg3) due to the extra 0.5% Magnesium.

• Ductility: It offers better elongation properties than 5454, making it superior for complex cold-forming.

• Corrosion: Like its siblings, it is exceptionally resistant to seawater and atmospheric corrosion.

---

Key Properties (Typical for H111/H22)

Property	Value
Density	2.66 g/cm3
Tensile Strength ($R_m$)	215 285 MPa
Yield Strength ($R_{p0.2}$)	100 200 MPa
Elongation ($A_{50mm}$)	14% 22%
Weldability	Excellent (TIG/MIG)

---

Chemical Composition (Weight %)

The balance of Magnesium and Manganese is critical for the "A" variants stability:

• Magnesium (Mg): 3.1% 3.8%

• Manganese (Mn): Max 0.50%

• Chromium (Cr): Max 0.20%

• Iron (Fe): Max 0.50%

• Silicon (Si): Max 0.50%

• Aluminum (Al): Remainder

---

Industrial Applications

• Pressure Vessels: Used heavily in the construction of storage tanks and boilers.

• Cryogenic Equipment: Maintains its toughness at extremely low temperatures.

• Welded Tubes: Often used for manufacturing high-quality welded aluminum piping.

• Automotive/Transport: Structural parts for heavy-duty trailers and tankers.

• Wire Production: 5154A is a preferred alloy for manufacturing aluminum rivets and welding wires.

---

Available Forms

1. Sheets: Common in 1.0mm to 5mm thickness for paneling and tank walls.

2. Plates: Available in thicknesses up to 150mm for structural machining.

3. Blocks: Often used as "mold blocks" for plastic injection or vacuum forming where medium strength and high thermal conductivity are required.

Pro Tip: If you are welding 5154A, use 5183 or 5356 filler wire. These magnesium-matched fillers ensure the weld zone doesn't become the "weak link" in terms of corrosion resistance.

Excellent Corrosion and Heat Resistance

Manufactured with 3.1-3.9% magnesium, 5154A - AlMg3.5A aluminium alloys deliver outstanding corrosion resistance, especially in marine and industrial environments. They maintain structural integrity and mechanical properties up to 200C, ensuring dependable long-term performance in challenging conditions.


Versatile Applications and Superior Properties

With high weldability, good machinability, and a balance of strength and ductility, 5154A - AlMg3.5A products are favored for fabrication in transportation, construction, pressure vessels, and marine industries. Their non-magnetic nature, recyclable composition, and smooth mill finish further enhance their suitability for a wide range of engineering and industrial projects.


Custom Sizing and Professional Supply

Available in thicknesses from 1mm to 200mm and in both standard and tailored dimensions, 5154A plates, sheets, and blocks are provided by reputable dealers, manufacturers, and suppliers throughout India. Customers benefit from adherence to DIN/EN standards and options for specialized finishes or coatings upon request.
